Description

Length o.a. 22,02 m
Length between perpendiculars 19.75 m
Length w.l. 19,58 m
Breadth o.a. 8,60 m
Breadth hull 7.97 m
Draft 1,92 m
Depth 3,16 m
Displacement 80 t
Lightship 60,6 t
Gross tonnage 110 t
Net tonnage 31 t

Deadweight 18 t
VCG 3,93 m above BL
LCG 9,16 m from AP
TCG 0,02 m from CL
Service speed 22 kn
Main engine 2x MTU 10V2000M72 (900 kW/2250 rpm)
Gear box 2xZF 3000
Propeller 2x5 bladed RH and 2x5 bladed LH
Bow-thruster 2xSleipner
Auxiliary engine 2xCummins Onan MDKBR
Fuel on board 2x4500L
Fresh water on board 1000L
Decks 1
Machinery notation LMC, UMS
Hull notation 100A1 SSC Work Boat, Catamaran, HSC, G3
Manning on board 3 crew members and 12 passengers,

Hull Equipment and Accommodation
Watertight door Libra WR100-WT
Window wiper Exalto
Window wiper control Exalto
Interceptor Humphree
Rescue star and crane Global Davit
Crane remote control HS Marine Scanreco
Breathing apparatus Spasciani
Full face mask Spasciani
Emergency escape breathing Ocenco
Microwave oven Bosch
Dryer Bosch
Car radio Clarion
TV Philips 5000 series
Blue ray disc/DVD wireless LGHLX55W
Propulsion Machinery
Main engine MTU
Auxiliary engine Cummins Onan MDKBU
Gearbox ZF
Simplex compact seal Simplan SIC-P

Bow thruster Sleipner SidePower
Propeller Teignbridge 1050
Fuel pump Piusi Panther 56-72
Fuel filter Separ 2000
Fuel tank overfill Jotel YTE-101
Machinery Systems
Boiler Kabola HR series
Central heatin circulation Nocci
Circulation pump Grundfos UP
Ventilation unit Vent-Axia
Ventilation unit Veab CWW
Airconditioner Fujitsu R410A
Air conditionier unit Dometic B3300
Air vent Vetus Airvent
Fire pump Gianneschi BMA
Bilge pump KPM Marine
Manual bilge pump Whale Gusher
Fresh water pump Grundfos JP
Water boiler Isotemp
Hot water circulation Wilo Star-Z
Waste water pump GMP
Toilet pump Grundfos Sololiftt
Auxiliary engine cooling Bloxma Box Cooler
Electrical Installations
Electricity meter ABB Deltaplus/Deltamax
Navigation lights AquaSignal series 65
Searchlight ColorLight
Manual searchlight Wiska HML-ISO 35
Fire detection system Deckma
Fog horn Zöllner Zetfon
Battery charger Victron Energy Multiplus
GMDSS battery charger Victron Skylla
Montoring system Böning
Navigation Installations
Navigation radar Furuno MFDBB
Observation radar Furuno FAR-2117
Display Hatteland
Rudder indicator Simrad IS70/IS80
Rudder angle indicator Deif TRI-2
Quad processor Santec
Magnetic compass Cassens & Plath
GPS compass JRCJLR21
Echo sounder Furuno FE-700

Depth transducer Airmar
Autopilot Simrad AP70/AP80
Autopilot joystick Simrad 80
Weather Station Airmar 200WX
Weather infobox Morer
ECDIS Furuno FMD
Communication Installations
IP handset Thrane & Thrane
MF/HF radio Sailor 6300
VHF Sailor 6222
Portable VHF Sailor SP 3520
Direction finder Rhoteta RT 300
EPIRB Sailor SE 406
Satellite network Sailor 6120
Satellite control panel KVH TracVision M5/M7
Fleet broadband Sailor 500
Satellite repeater Simrad DR76
Navtex JRC NCR 333
AIS Saab R4
SAT Phone Iridium



ME PS - 1753Hrs
ME SBS - 15035Hrs
ME PS - 9894Hrs
AE SBS - 9205Hrs
next dry dock - 2026
