Description

Specifications
Length (moulded & LOA) : 14.00 m
Beam (moulded & OA) : 3.85 m
Depth (moulded) : 1.90 m
Draft (moulded) : 0.70 m
Construction Hull/ Wheelhouse : Aluminium

Classification and certificates
BV – Fast Pilot Boat
COASTAL AREA

Propulsion and Main Engine: : - Twin FPT N67ENTM45
2X 420HP@3000 RPM
- 2x ZF 280 IV
- 2x FPP

Speed and Range:
Service Speed : 24 knots
Maximum Speed : 26 knots
Range (at service speed) : 650 nautical miles
Operation Hr : 24 hours

Tank Capacities:
Fuel : 3.5 m3
Freshwater : 0.3 m3
Sewage tank : 0.2 m3
Oily water (bilge) tank : 0.04 m3

Deck Equipment:
4 bollards
Anchor
Anchor Cable 30m



Auxiliary engines:
Sole diesel generator : 1 x 9.4kW

Life Saving Equipment:
2 x 16 persons inflatable life raft
Buoys and life jackets min. as per reg.

Fire Fighting Equipment:
Portable Powder tubes
Portable CO2 tubes and fire stations

Accommodation:
Crew : 2 persons
Pilots or passengers or survivors: 28 persons
Wheelhouse
WC and shower
Heating or cooling via A/C in all areas


Navigation Equipment:
Navico BR24 BroadBand 3G Radar
NSS12 Evo2 COMBO Multi Touch Screen MFD Chartplotter
GS25 GPS Navigator
P319 Echo Sounder
Magnetic Compass
Horn
Searchlight
Navigation lights
Navtex - NX-300 Navtex Receiver
Aıs - NAIS-500 Class B AIS System with GPS-500 Antenna

Communication Equipment:
RS20 Marine VHF Radio with Class-D DSC


General Specifications:
Double chine planning hull
Corrosion resistance full aluminium hull & super-structure
360-degree view at bridge
Absorbing D100 mm fender system
Ergonomic and comfortable internal layout

Specifications

Accommodation

PICTURES CAN BE SENT UPON A REQUEST

Construction

PICTURES CAN BE SEND UPON A REQUEST

Equipment

PICTURES CAN BE SENT UPON A REQUEST

Navigation Equipment

PICTURES CAN BE SENT UPON A REQUEST

Engine(s)

- Twin FPT N67ENTM45
2X 420HP@3000 RPM
- 2x ZF 280 IV
- 2x FPP

Sails & Spars

PICTURES CAN BE SENT UPON A REQUEST
